Surface Core Drilling rig

A Surface Core Drilling Rig is a type of drilling equipment used primarily in mineral exploration and geotechnical investigations to obtain core samples from the earth's surface. Unlike other drilling methods, core drilling involves extracting cylindrical samples of rock or soil to study the geological conditions below the surface.


Advantages of Surface Core Drilling

High-Quality Samples: Provides detailed and uncontaminated core samples, essential for accurate geological and geotechnical analysis.

Deep Penetration: Capable of drilling to significant depths, often reaching several hundred meters.

Versatility: Surface drilling rigs can be used in various geological conditions, including hard rock and soil.


The Surface Core Drilling Rig is an essential tool for obtaining high-quality core samples from the earth's surface. Its design, including the drill rig, core barrel, and power supply, ensures efficient drilling and sample collection. It is widely used in mineral exploration, geotechnical investigations, and environmental studies, providing valuable data for various applications.

Read More

  • JCDRILL JCD150 Crawler Hydraulic Surface Diamond Core Drilling Mining Drilling Rigs

    JCDRILL JCD150 Crawler Hydraulic Surface Diamond Core Drilling Mining Drilling Rigs

    Hole Depth: 200,150,120 m

    Dimension:2750*1500*1650 mm

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD150 Full Hydraulic Portable Drilling Rig is a kind of light rig designed for geological exploration in remote area difficult to enter. It is mainly suitable for diamond drilling with wire line coring technique.


  • JCD300 Hydraulic Diamond Core Drilling Rig

    JCD300 Hydraulic Diamond Core Drilling Rig

    Hole Diameter: 65-213mm

    Max. Drilling Depth:300m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD300 core drilling rig is a kind of lightweight fully hydraulic core drilling machine for geological exploration, and it is portable. It is mainly used in complex terrains and inaccessible areas, and it is especially appropriate for diamond wireline core drilling technology.

    Its main components include diesel power drill, hydraulic system, control system, main winch, wireline winch, power head, feeding system, feed system, and gripper (holder) for well mouth.


  • JCD300S  Exploration Mine Diamond Core Drilling Rigs Machine

    JCD300S Exploration Mine Diamond Core Drilling Rigs Machine

    Drilling Depth: 300,200,80 m

    Core Diameter:42.1/56.1/71.3 mm

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

     JCD300S Full Hydraulic Portable Drilling Rig is a kind of light weight core drilling rig designed for geological exploration in remote area difficult to enter.


  • JCD400 Diamond core drilling mining rig for ore sample Full Hydraulic Portable Drilling Rig

    JCD400 Diamond core drilling mining rig for ore sample Full Hydraulic Portable Drilling Rig

    Drilling Depth: 400 300 100 m

    Diameter:14 mm

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD400 Full Hydraulic Portable Drilling Rig is a kind of light rig designed for geological exploration in remote areas difficult to enter. It is mainly suitable for diamond drilling with the wireline coring technique.

  • JCD600 Full Hydraulic Crawler Mounted Diamond Borehole Core Mining Drilling Rig Machine

    JCD600 Full Hydraulic Crawler Mounted Diamond Borehole Core Mining Drilling Rig Machine

    Drilling Diameter: 60.1/75.7/95.5 mm

    Drilling Depth:600 400 260 m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD600 core drilling rig is a kind of lightweight fully hydraulic core drilling machine for geological exploration, and it is portable. It is mainly used in complex terrains and inaccessible areas, and it is especially appropriate for diamond wireline core drilling technology.

    Its main components include diesel power drill, hydraulic system, control system, main winch, wireline winch, power head, feeding system, feed system, and gripper (holder) for well mouth.


  • JCD800 Full Hydraulic Diamond Core Drilling Rig Supplier

    JCD800 Full Hydraulic Diamond Core Drilling Rig Supplier

    Hold Diameter: 121mm

    Drilling Depth:1000,700,500,300m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD800-The core drill rig of full hydraulic and rotator adopted the technology of wire-line coring has been the dominant type rig for solid mineral deposits prospecting in developed counties in the world. It is also the developing direction of drilling technique and drilling equipment in China.

  • JCD1000 Full Hydraulic Diamond Core Drilling Rig

    JCD1000 Full Hydraulic Diamond Core Drilling Rig

    Hold Diameter: 121 mm

    Drilling Depth:1000 700 500 300 m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD1000-The core drill rig of full hydraulic and rotator adopted the technology of wire-line coring has been the dominant type rig for solid mineral deposits prospecting in developed counties in the world. It is also the developing direction of drilling technique and drilling equipment in China.

  • JCD1200 Core Drill Rig Hydraulic Borehole Drilling Equipment Geological Core Drilling Machine

    JCD1200 Core Drill Rig Hydraulic Borehole Drilling Equipment Geological Core Drilling Machine

    Hold Diameter: HTW-NTW-BTW

    Drilling Depth:1500 1200 500 m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD1200-The core drill rig of full hydraulic and rotator adopted the technology of wire-line coring has been the dominant type rig for solid mineral deposits prospecting in developed counties in the world. It is also the developing direction of drilling technique and drilling equipment in China.

  • JCD1500 Mineral Exploration Drilling Rig Surface Core Drilling rig

    JCD1500 Mineral Exploration Drilling Rig Surface Core Drilling rig

    Drilling Diameter: NQ,HQ,PQ

    Max. Drilling Depth: 700,1000,1500m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD1500 Full Hydraulic Portable Drilling Rig is a kind of light rig designed for geological exploration in remote area difficult to enter.It is mainly suitable for diamond drilling with wire line coring technique. The rig consists of diesel power unit, hydraulic system, control panel, mast, main winch, wireline winch, drill head, feed system, footclamp, etc.
