Drilling Tools

  • DTH Hammer DTH Drilling Tools for Hard Rock

    DTH Hammer DTH Drilling Tools for Hard Rock

    Size Range2 to 24 inch

    ShanksDHD,MISSION,SD,QL,CIR


    >> Application

    DTH drilling is a percussion system driving a piston inside hammer body with up and down motion by compressed air and transmitting an intensive percussion energy to the bit to enable the drilling by crushing the rock. Drilling method by DTH hammer exerts high drilling performance especially for drilling hard rock and contributes for shortening work schedule. Hence, this method is widely utilized for foundation work, landslide prevention work, quarrying services, marine civil work, etc.

  • DTH Drilling Button Bits For Quarry And Road Construction Drilling With Air Compressor

    DTH Drilling Button Bits For Quarry And Road Construction Drilling With Air Compressor

    Size Range: 3 to 40 inch

    ShanksDHD,MISSION,SD,QL,CIR

    Type:With or without foot valve


    >> Application

    DTH (Down The Hole) drill bit, also called spline connected drill bit, is mainly used in large scale mine (open and underground), open quarry and construction. The hammer is situated down the hole in direct connected with the drill bit with splines in the bit. The hammer piston strikes the drill bit resulting in an efficient transmission of the impact energy and insignificant power losses with the hole depth.

  • DTH Drill Pipes/Drill Rod For Mining Drill Rig With DTH Hammer

    DTH Drill Pipes/Drill Rod For Mining Drill Rig With DTH Hammer

    Length:0.5 to 12 m

    Out Diameter:50,60,76,89,102,114,127

    Head Diameter:26/28/30/32/34/36/38


    >> Application

    The drill pipe, the shortened form of down the hole drill pipe, is a kind of outer flat drill rod. It is mainly used in rotary percussive drilling that contains gases and liquids. Its main components include pipe (rod) body and joint.

  • Eccentric Overburden Drilling Casing System For Well Drilling

    Eccentric Overburden Drilling Casing System For Well Drilling

    Model:Eccentric Casing System

    Casing Tube:108,114,127,146,168,178

                          ,183,194,219,245,273,325,377


    >> Application

    The eccentric reamer drill is an overburden drilling system designed for conditions where a cased hole is required. Collapsing holes tend to make overburden drilling expensive, with lost drilling equipment and down time.

  • Drilling Concentric Overburden Drilling Systems Reamer

    Drilling Concentric Overburden Drilling Systems Reamer

    Model:Concentric Casing System

    Casing Tube:146,168,178,183,194,219

                          ,245,273,325,377


    >> Application

    Concentric Drilling Tools is suitable for drilling water wells , geothermal wells , short miscopies ,medium mini-type grouting hole of building , dam and harbor project .

  • DTH Sub Adapter Down The Hole Hammer Rod Adaptor

    DTH Sub Adapter Down The Hole Hammer Rod Adaptor

    TypeBox to Box, Pin to Pin, Box to Pin

    Thread: API REG,IF


    >> Application

    A Sub Adapter, a special short length of pipe with a drill pipe connection on the top and a drill collar connection on the bottom, is added before a drill pipe can be screwed onto the drill collars.

  • TCI Tricone Bit For Water Well Drilling

    TCI Tricone Bit For Water Well Drilling

    IADC CODE:417 437 517 537 617 637 737 837


    >> Application

    The tricone drill bit is the most popular drill bit in the world, it can be widely used for oil&gas drilling, mining, water well, geological exploration areas.Our tricone drill bit is divided into metal sealed drill bit and rubber sealed drill bit.

  • Tricone Bit Water Well Steel Tooth Rock Roller Bit For Sale

    Tricone Bit Water Well Steel Tooth Rock Roller Bit For Sale

    IADC CODE:117 127 217



    >> Application

    Tricone bits, which some may also call roller cone bits or tri-cone bits, have three cones. Each cone can be rotated individually when the drill string rotates the body of the bit. The cones have roller bearings fitted at the time of assembly. The rolling cutting bits can be used to drill any formations if the proper cutter, bearing, and nozzle are selected.

  • High Quality Steel Body Pdc Drill Bit For Oil Or Water Well Drilling

    High Quality Steel Body Pdc Drill Bit For Oil Or Water Well Drilling

    IADC CODE:M223 M322 S223 S332 322


    >> Application

    PDC bit used for geoloical prospecting,development of oil and gas,drilling water wells,blast holes and making holes for seismic prospecting,construction engineering.now there are 2 types: Matrix and Steel Body.
