Mineral Exploration Drilling Rig

Jcdrill Mineral exploration drilling rigs include core drilling rig and reverse circulation (RC) drilling rig, mainly apply to exploration and prospecting of geology, metallurgy, coal, nuke industry, and hydrology.


Our core drilling rig include surface core drilling and underground core mining, mainly use wireline diamond core drilling technology, depth capacity from 50m to 2500m drilling capacity.


Jcdrill's RC drilling rig range from 50m-1200m, all RC drilling rig can be equipped on truck, crawler and trailer as user's demand, automatic rod change, hydraulic clamp, three-layer cyclone, blow down valve are available for option.

Read More

  • JCD300SPT

    JCD300SPT

    Model: JCD1500

    Max. Drilling Depth: 700,1000,1500m

    Drilling Method: Wireline Diamond Core Drilling


    >> Application

    JCD1500 Full Hydraulic Portable Drilling Rig is a kind of light rig designed for geological exploration in remote area difficult to enter.It is mainly suitable for diamond drilling with wire line coring technique. The rig consists of diesel power unit, hydraulic system, control panel, mast, main winch, wireline winch, drill head, feed system, footclamp, etc.

  • JXY130 Core Drilling Rig for Drilling Well, Census Exploration

    JXY130 Core Drilling Rig for Drilling Well, Census Exploration

    Hold Diameter: 75 mm

    Drilling Depth: 130 m

    Drilling Method: Spindle core drilling rig


    >> Application

    The drill for drilling wells, census exploration, geophysical exploration, road and building exploration and blasting drilling and other drilling projects.

    According to the bottom of the different choice of alloy, diamond and composite drill bits and other drilling.

    Can drill 2-9 level of sandy clay and rock formations.


  • JXY200 Diamond Core Drill Rig for Mine Projects

    JXY200 Diamond Core Drill Rig for Mine Projects

    Hold Diameter: 75 mm

    Drilling Depth: 200 m

    Drilling Method: Spindle core drilling rig


    >> Application

    XY-200 type drill based on the ordinary drill increase drill shift chute, which can realize quick change tool to improve the work efficiency to reduce Labour intensity.

    The machine is used for the high-speed drilling machine is suitable for the exploration, geophysical exploration, road and building exploration and blasting hole drilling engineering, etc and it can be selected according to the underlying different alloy, diamond, compact drill for drilling, etc.

  • JXY600 Portable Hydraulic Core Drilling Rig

    JXY600 Portable Hydraulic Core Drilling Rig

    Hold Diameter: 75 mm

    Drilling Depth: 600 m

    Drilling Method: Spindle core drilling rig


    >> Application

    XY-600 type drill based on the ordinary drill increase drill shift chute, which can realize quick change tool to improve the work efficiency to reduce Labour intensity.

    The machine is used for the high-speed drilling machine is suitable for the exploration, geophysical exploration, road and building exploration and blasting hole drilling engineering, etc and it can be selected according to the underlying different alloy, diamond, compact drill for drilling, etc.


  • XY-5A Spindle Hydraulic Core Drilling Rig

    XY-5A Spindle Hydraulic Core Drilling Rig

    Hold Diameter: 43-89 mm

    Drilling Depth: 1800 to 900 m

    Drilling Method: Spindle core drilling rig


    >> Application

    HXY-5A spindle type core drilling rig usually takes diamond bit or hard tungsten-carbide tipped bit. It is widely applied in the field of geology, metallurgy, coal mine, hydrological and engineering drilling. It is mainly suitable for exploration of metal or non-metal solid mineral ore bed. It can also be used in the exploration of superficial-zone petroleum and natural gas, mines' ventilation and water discharge tunnel drilling as well as large-diameter foundation piling.

  • XY-42A Core Drilling Machine for Geological Exploration

    XY-42A Core Drilling Machine for Geological Exploration

    Rod size: 42-89 mm

    Drilling Depth: 1200 to 430 m

    Drilling Method: Spindle core drilling rig


    >> Application

    The XY-42A spindle type core drilling rig can be applied to coring drilling by using tungsten-carbide-tipped bit and diamond bit. It is also called surface core drill rig in general place. It can be also used to engineering geological exploration, hydro-geological, water well drilling and big foundation hole as well as basic piling hole.


  • XY-44A Rotary Surface Core Drilling Rig

    XY-44A Rotary Surface Core Drilling Rig

    Hold Diameter: 42-89 mm

    Drilling Depth: 1400 to 300 m

    Drilling Method: Spindle core drilling rig


    >> Application

    XY-44A Core Drilling Rig is a core drilling equipment based on diamond and carbide drilling. It is mainly used in geology, metallurgy, coal, hydrology, engineering and other industries. It can also be used in engineering geological exploration, shallow oil and natural gas exploration , Mine tunnel ventilation, drainage, hydrological wells drilling and large diameter foundation pile construction.


  • XY-4T Core Drilling Machine for Drilling Sample

    XY-4T Core Drilling Machine for Drilling Sample

    I.D of Spindle : 68 mm

    Drilling Depth: 700 to 1000 m

    Drilling Method: Spindle core drilling rig


    >> Application

    The XY-4T core drill rig, integrated rig with tower into one unit, consists of XY-4 drill rig and mast-type drill tower, with the function of hydraulic lifting and lowering of tower. The rig is simple in structure, reasonable in design, light in weight, easy to operate; it is in a wide range adjusting angle. It is especially suitable for drilling of

    hole with great slope angle.

    The tower body of XY-4T Drill Rig is used as lifting drill tools for drilling vertical as well as inclined holes. The range of adjusting angels (in clock-wise direction) for drilling inclined holes is 0°-90°.


  • XY-44T Core Drilling Machine for Drilling Deep Hole

    XY-44T Core Drilling Machine for Drilling Deep Hole

    I.D of Spindle : 93 mm

    Drilling Depth: 700 to 1400 m

    Drilling Method: Spindle core drilling rig


    >> Application

    The XY-44T core drill rig, integrated rig with tower into one unit, consists of XY-44 drill rig and mast-type drill tower, with the function of hydraulic lifting and lowering of tower. The rig is simple in structure, reasonable in design, light in weight, easy to operate; it is in a wide range adjusting angle. It is especially suitable for drilling of hole with great slope angle.

    The tower body of XY-44T Drill Rig is used as lifting drill tools for drilling vertical as well as inclined holes. The range of adjusting angels (in clock-wise direction) for drilling inclined holes is 0°-90°.
